Dimmable LED Waterproof Light

The exceptionally durable LED weatherproof light from the outstanding TRILAMP A4 family demonstrates robust corrosion resistance and is highly suitable for damp or humid environments. The distinguished factory, Fanxstar, specifically focuses on the top-notch production and substantial supply of LED tri-proof lamps in China. When LED tri-proof lighting truly carries great significance, you sincerely aim to present your discerning customers with the outright top and diverse aspects in terms of quality and selection. The renowned Fanxstar offers you all of that and even more, presenting a comprehensive and diverse range of easily installable LED tri-proof luminaires for every diverse application and varying situation. Fully relish more outstanding performance and abundant variety with Fanxstar – the comprehensive assortment of high-quality exquisite LED tri-proof lighting that is setting a distinct reference in the market.

Send Inquiry

Product Description

FANXSTAR 0.01-100% Professional Dimming Waterproof Light Trilamp A4 DA
DALI2.0 5.8G Microwave & PIR Sensor as Opitons

With the popularity of DALI dimming technology in Europe, especially after DALI2.0 supports wireless solutions and a variety of expansion interfaces, more and more LED lighting products have joined them, and our latest Tri-proof Trilamp A4-DA Dimming series led weatherproof lighting products are no exception.

The conventional led triproof products only have the functions of steady on, microwave induction and emergency, and the new A4-DA series has added the control function of DALI2.0, which can remotely address, network, brightness control and working status monitoring of the lamp through the main control room.

Trilamp A4 family keeps pace with technological advances, the new Trilamp A4-DA Dimming series of the Tri-proof lamp offers us a solution with energy savings of more than 80% compared to conventional solutions and alternatives.

FANXSTAR Tri proof LED luminaires Trilamp A4 DA Specification

Item	Part Number	A4-2FT20-MMK-DA		A4-4FT40-MMK-DA	A4-5FT60-MMK-DA
	Description	Professional Dimming LED Weatherproof Batten
Working	Mode of Operation	DALI2.0, 0.01-100% Dimming
Input	Voltage&Frequency	220-240Vac, 50/60Hz
	Wiring Connection	923 terminal blocks, Loop in and Loop out
Output	Light Source	High lumens SMD2835
	Color Temperature	MM=27-65 stands for 2700-6500K
	Luminous Flux	140lm/w±10%
	Power Consumption	20W		40W	60W
Controls	Protection	Overcharge, low voltage disconnect, overcurrent, short circuit
	Multimode	DALI2.0 Sensor, Brightness Control, 0-10V Dimmable as options
Physical	Construction	Diffuser - high transmission opal polycarbonate, chassis -polycarbonate
	Mounting	Surface mounted - ceiling / wall /suspend
	Colour	Gray RAL7035
	Dimensions L x W x H(mm)	600x95x82	1200x95x82		1500x95x82
	IP/IK Rating	IP65 & IK10
	Weight	1.0kg	2.0kg			2.6kg
	Warranty	5 years on product
Environment	Operating Temperature	-30° to 50°C
	Relative Humidity	-10 to 95%
Compliance	Standards	CE/UKCA/RCM
Accessories	Dimming Sensor	P/N: A4-DAS: DA9033A
	Remote Control	NON
