Emergency Tri-proof LED Lamp

Fanxstar is an enterprise focused on the production and supply of LED tri-proof lamps in China. The Trilamp A9 exhibits an unparalleled mix of economically viable and high-performing LED weather-proof battens. In the last few years, we have been providing high-quality LED tri-proof luminaires at competitive prices to customers in more than 90 countries and regions across the globe. The Fanxstar team keeps in mind that we will actively cooperate with clients to continuously improve and explore more flexible, customizable, and user-friendly LED Tri-proof lights in the upcoming time.

Send Inquiry

Product Description

FANXSTAR LED Driver & Emergency Converter 2-in-1 Waterproof Emergency Batten A9

Integrated design of leds & emergency function in Trilamp A9-E series is a ideal and economic solution for projects and applications.

It has maximum in-service life and lowest maintenance cost. LED Tri-proof light TLA9 series has been upgraded to IK10 & IP66 rate, flicker-free, high efficiency output, Lightning surge L-N: 2kV L/N-FG: 4kV (IEC61000-4-5), which make less prone to damage in harsh environments.

The Emergency LED Tir-proof lighting fixture has suspended, walled and surfaced mounted version. Available in 1200mm-40W -120LPW and emergency 2W3HRS versions with LiFePO4 battery.

These high-performance parameters aqures higher-quality and longer-life for LED tir proof lamp A9-E.

FANXSTAR LED Tri-proof light Trilamp A9 Specification

Item	Part Number	A9-2FT20-MMK- E	A9-4FT40-MMK-E
	Description	Driver & Emergency Converter 2-in-1 Waterproof Emergency Batten
Working	Mode of Operation	Maintained
Input	Voltage&Frequency	220-240Vac, 50/60Hz
	Wiring Connection	923 terminal blocks, Loop in and Loop out
Output	Light Source	High lumens SMD2835
	Color Temperature	MM=27-65 stands for 2700-6500K
	Luminous Flux	140lm/w±10%
	Power Consumption	20W		40W
Controls	Protection	Overcharge, low voltage disconnect, overcurrent, short circuit
	Multimode	Standy, Microwave Sensor and Emergency
Emergency	Charger	16hr intelligent 3-stage charger with battery management system
	Emergency Power	2W		3W
	Duration Time	3 hours		3 hours
	Testing Facility	Manual test, Self test
	Indicators	Battery charger green LED, Function failure through red LED.
Physical	Construction	Diffuser - high transmission opal polycarbonate, chassis - polycarbonate
	Mounting	Surface mounted - ceiling / wall
	Colour	Gray RAL7035
	Dimensions L x W x H(mm)	600x83x72 1200x83x72		600x83x72 1200x83x72
	IP/IK Rating	IP66 & IK10
	Weight	1.0kg		2.0kg
	Warranty	5 years on product, 3 years on battery
Environment	Operating Temperature	-20° to 50°C
	Relative Humidity	-10 to 95%
Compliance	Standards	CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293
	AS/NZS 2293 Classification	C0 D63, C90 D40
Accessories	Microwave Dimming Sensor	P/N: A9S: FS010ER
	Replacement Battery	P/N: A9E: LiFePO4 6.4V 1600/2000mA
