Full Voltage LED Down Light

Fanxstar proudly spearheads the LED downlights industry as a distinguished manufacturer and supplier in China, spotlighting our hallmark product, the Allstar D3—an embodiment of our commitment, boasting an exceptional 85-265V Full Voltage LED Down Light and an IP65 waterproof High output LED down lighting solution.
Over 7 years, our steadfast dedication has been to deliver premium LED downlight luminaires at competitive prices, catering to the discerning needs of our esteemed clients. Our global reach extends across 90 countries and regions, facilitated by our robust export network, fortifying our established presence worldwide. Our continual pursuit revolves around proactive collaboration with partners and customers, aimed at consistently elevating and innovating more adaptable, customized, and user-friendly LED downlight fixtures. This enduring dedication serves as the bedrock of our mutually advantageous business model, fostering growth and prosperity for all stakeholders involved.

Send Inquiry

Product Description

FANXSTAR 85-265VAC full voltage LED DOWNLIGHTS Allstrar D3

Low-Voltage DOWNLIGHTS For Centralized Control

Allstar DX 10-60W LED downlights Full Voltage LED Down Light have high protection levels, such as IP42/IP54/IP65, to provide better safety and protection performance. This type of LED down light is suitable for outdoor, humid areas or industrial places, with waterproof, dustproof, anti-corrosion and other characteristics, can work in harsh working environment for a long time without damage. In 6 "and 8" sizes, 60W high power and 7200lm lumen output can be achieved to illuminate the entire area, meeting the lighting needs of specific places in the lobby or outdoor corridor. Allstar DX LED down lighting has two versions emergency: conventional application has 2/3/5W manual, automatic and Dali2.0, as well as the centralized control emergency system with the built-in DC24V/36V low voltage or built-in address controller application. The low voltage characteristics of Allstar DX LED down lights luminaire series can also be used in special and new energy fields such as explosion-proof and solar energy storage.

FANXSTAR LED Shop Down Light Allstar DX Full Voltage LED Down Light Specification

Item	Part Number	D1-4S15-MMK-E	D2-4S09-MMK-N	D3-4S18-MMK-N	4-4S05-MMK-1
	Description	IP65 Recessed All-in-one LED Downlight
Working	Mode of Operation	Multimode - Maintained / Non-Maintained
Input	Voltage &Frequency	220-240Vac\|24Vac/dc, 50/60Hz
	Installation	Complete with 1.2m flex cable & plug for Australia
Output	Light Source	High lumens SMD2835
	Luminous Flux	120lm/w±10%
	Power Consumption	15W(Maintained)	9W(Standy)	18W(Standy)	5W(Standy)
Controls	Protection	Overcharge, low voltage disconnect, overcurrent, short circuit
	Multimode	Low-voltage, Microwave Sensor and Emergency for optional
Emergency	Charger	16hr intelligent 3-stage charger with battery management system
	Emergency Power	2W (Non-Maintained)
	Duration Time	> 180 minutes
	Testing Facility	Manual test
	Indicators	Battery charger green LED, Function failure through red LED.
Physical	Construction	UL94V0 Flame-retardant polycarbonate, chassis - Aluminium
	Mounting	Recessed - ceiling, 120 - 140mm cut-out
	Colour	White
	Dimensions L x W x H	Disc: 155mm diameter x Height: 53mm
	IP Rating	IP65
	Weight	640g
	Warranty	5 years on product, 3 years on battery
Environment	Operating Temperature	0° to 50°C
	Relative Humidity	0 to 95%
Compliance	Standards	CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293
	AS/NZS 2293 Classification	C0 D32, C90 D32
Accessories	Replacement Battery	P/N: BAT-ONE: LiFePO4 3.2V 3200mA
