Low Voltage LED Down Light

Fanxstar proudly leads the LED downlights Low Voltage LED Down Light industry as a distinguished manufacturer and supplier in China, shining a spotlight on our flagship product, the Allstar D4—an epitome of our dedication, featuring an outstanding 24V, 36V, 48V low Voltage LED Down Light and an IP65 waterproof High output LED down lighting solution.
For the past 7 years, our commitment has remained resolute in delivering top-tier LED downlight luminaires at competitive prices to our valued clients. Our global footprint spans across 90 countries and regions through our robust export network, firmly establishing our presence worldwide. Our ongoing commitment revolves around proactive collaboration with partners and customers, aiming to consistently enhance and innovate more adaptable, customized, and user-friendly LED downlight fixtures. This commitment is the cornerstone of our mutually beneficial business model, placing growth and stakeholder satisfaction at the forefront of our endeavors.

Send Inquiry

Product Description

FANXSTAR 24/36/48Vdc Low voltage LED DOWNLIGHTS Allstrar D4

Low-Voltage DOWNLIGHTS For Centralized Control

Allstar DX 10-60W 24v LED downlights Low Voltage LED Down Light have high protection levels, such as IP42/IP54/IP65, to provide better safety and protection performance. This type of 36v LED down light is suitable for outdoor, humid areas or industrial places, with waterproof, dustproof, anti-corrosion and other characteristics, can work in harsh working environment for a long time without damage. In 6 "and 8" sizes, 60W high power and 7200lm lumen output can be achieved to illuminate the entire area, meeting the lighting needs of specific places in the lobby or outdoor corridor. Allstar DX 48V LED down lights has two versions emergency: conventional application has 2/3/5W manual, automatic and Dali2.0, as well as the centralized control emergency system with the built-in DC24V/36V low voltage or built-in address controller application.The low voltage characteristics of Allstar DX low voltage LED down light series can also be used in special and new energy fields such as explosion-proof and solar energy storage.

FANXSTAR LED Down Light luminaire Allstar DX Low Voltage LED Down Light Specification

Item	Part Number	D1-4S15-MMK-E	D2-4S09-MMK-N	D3-4S18-MMK-N	4-4S05-MMK-1
	Description	IP65 Recessed All-in-one LED Downlight
Working	Mode of Operation	Multimode - Maintained / Non-Maintained
Input	Voltage &Frequency	220-240Vac\|24Vac/dc, 50/60Hz
	Installation	Complete with 1.2m flex cable & plug for Australia
Output	Light Source	High lumens SMD2835
	Luminous Flux	120lm/w±10%
	Power Consumption	15W(Maintained)	9W(Standy)	18W(Standy)	5W(Standy)
Controls	Protection	Overcharge, low voltage disconnect, overcurrent, short circuit
	Multimode	Low-voltage, Microwave Sensor and Emergency for optional
Emergency	Charger	16hr intelligent 3-stage charger with battery management system
	Emergency Power	2W (Non-Maintained)
	Duration Time	> 180 minutes
	Testing Facility	Manual test
	Indicators	Battery charger green LED, Function failure through red LED.
Physical	Construction	UL94V0 Flame-retardant polycarbonate, chassis - Aluminium
	Mounting	Recessed - ceiling, 120 - 140mm cut-out
	Colour	White
	Dimensions L x W x H	Disc: 155mm diameter x Height: 53mm
	IP Rating	IP65
	Weight	640g
	Warranty	5 years on product, 3 years on battery
Environment	Operating Temperature	0° to 50°C
	Relative Humidity	0 to 95%
Compliance	Standards	CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293
	AS/NZS 2293 Classification	C0 D32, C90 D32
Accessories	Replacement Battery	P/N: BAT-ONE: LiFePO4 3.2V 3200mA
