Full Voltage LED Battens

Fanxstar takes pride in standing at the vanguard as a premier manufacturer and supplier of Full Voltage LED Battens based in China. Our illustrious Batman B1 serves as IP40 multi-purpose modular diffused LED waterproof batten that highlights our unswerving dedication to establishing quality and competitiveness standards.

Send Inquiry

Product Description


Best Partner For FX Weatherproof Splice System
IP40 Multi-Purpose Modular Diffused LED Waterproof Batten Batman B1

Throughout the past 7 years, our core mission has remained unwavering: providing outstanding Full Voltage LED Battenss recognized for their superior quality and competitive pricing. Our global reach encompasses 90 countries and regions, supported by our strong export network. Our commitment remains unshakable: actively interacting with partners and clients to continuously innovate and develop LED batten lights that prioritize adaptability, personalization, and user-centered design. This unwavering commitment propels us towards a mutually beneficial business model, ensuring success and satisfaction for all stakeholders involved.

Designed from the ground up, the Batman B1-GU is a unique diffused LED linkable batten featuring with Aluminum 6063 heatsink to improved heat dissipation. Engineered with modular LED strips and end-caps allowing the mask tray to drop for fast and toolless reassembly after sale service.

In the replacement projects, led weatherproof batten Batman B1-GU with 118mm width rarely needs to repaint the installation position, which allows for an extremely easy and quick installation. 1:1 replacement for 2-tubes fluorescents, made by more affordable price, better quality and more energy saving.

Constructed to be a versatile solution for all applications, the led linear batten Batman B1-GU has numerous mounting options, such as Intelligent 5.8G Microwave Sensor and 3hrs Emergency kits, which matched with premium components for unparalleled performance.




LED Batten lighting Ordering Guide


FANXSTAR LED Batten Fixtures Batman B1 Specification

LED Batten Specifications data with 600mm length

Version Item No. Description MM=Color temp. Luminous flux
Normal B1-2FT20-MMK-N 2' Diffused LED Batten light,
Voltage100-277V 50/60Hz,
Power 20W, 80CRI, 20-65K
LED Qty 90pcs
2700-6500K 120 lm/W

LED Batten Specifications data with 1200mm length

Version Item No. Description MM=Color temp. Luminous flux
Normal B1-4FT40-MMK-N 4' Diffused LED Batten light,
Voltage100-277V 50/60Hz,
Power 40W, 80CRI, 20-65K
LED Qty 180pcs
2700-6500K 120 lm/W

LED Batten Specifications data with 1500mm length

Version Item No. Description MM=Color temp. Luminous flux
Normal B1-5FT60-MMK-N 5' Diffused LED Batten light,
Voltage100-277V 50/60Hz,
Power 60W, 80CRI, 20-65K
LED Qty 220pcs
2700-6500K 120 lm/W


FANXSTAR LED Batten light fixtures Batman B1 Feature And Application

Unique design for No shadow without light lens

118mm width, instead of T5/T8 fluorescent double-tubes

IP40 protection, effectively prevent mosquitoes from entering

PA14/923 Terminal blocks, series connection according to project needs


LED Linear Batten Wiring Diagram


FANXSTAR LED Batten lights Batman B1 Details

Replaceable LED Driver and Strips, rear and end cable entry options of LED Batten Lights

LED Fixtures Batten 1:1 replacement for 2-lamps T5/T8 fluorescent

No shadow diffuser/prism made by Unique design, Premium AL6063 body for improved heat dissipation LED Batten Lamp

0-10V/DALI Dimming, Emergency and Sensor options available of Emergency LED Linear Batten


LED Batten Batman B1 Dimensions


LED Battens Batman B1 Packing


LED Batten Installation

Surface mounted and suspend mounted available
